ASSEMBLY OF APPARATUS FOR DETERMINATION OF CARBONATE IN LIME AS PER IS 1514:1990 (R.A.2020)

The apparatus shall consist of the following components assembled as given

a) Funnel (A );

b) Two-way cock ( B );

c) 50-ml flask ( C );

d) Leveling bottle ( D );

e) Condenser tube ( E );

f) Water jacket ( F );

g) Compensator tube ( G );

h) Gas burette ( H );

j) Manometer ( J );

k) Sodium hydroxide bubbler ( K);

m) Valve ( L ); and

n) Three-way cocks ( M, N, P, Q ).

The compensator tube is used to correct automatically for the changes in barometric pressure and temperature by balancing the pressure in the burette against that in the compensator tube. The manometer is used when balancing the pressure in the burette against that in the compensator tube.

(Chemicals required available at extra cost)

Note : On site assembly of the apparatus will be at extra cost. However actual demonstration of testing will not be possible by us
